HIKMICRO Thunder Zoom TQ60Z 2.0 (DEMONSTRATION ITEM)
Code: 3298Related products
Product detailed description
The combination of a reliable sight and optical zoom - that's the HIKMICRO Thunder Zoom 2.0! This device combines the bestthe widest thermal imaging sensor on the market today, with the ability to change the field of view and zoom in on the target without losing quality, offering a perfect image at long range.
- Sensor 640 × 512 px
- Temperature sensitivity ≤ 20 mK
- Detection up to 3000 meters
- Optical zoom and dual field of view
The Thunder Zoom TQ60Z 2.0 is equipped with a thermal imaging sensor with a NETDsensitivity ≤ 20 mK and a resolution of 640 × 512 px. The lower the NETD value, the better the sensor can record even the smallest temperature differences of objects and provide you with a detailed picture.
The optical zoom function consists of two lenses in one instrument, allowing you to change the width of the field of view according to your needs. A 35mm focal length lens with a fixed optical magnification of 1.8x gives the sight a detection range of 1,800 meters and a 60mm focal length lens with 3.1x magnification gives the sight a detection range of up to3,000 meters.
The entire image is rendered on a 1024×768 px OLED display, which offers comfortable viewing conditions that can be adjusted precisely for your eye.
With 16 GB of built-in storage, you can take photos and videos with audio. With a connection to the HIKMICRO Sight app, you can observe the scene in real time via your mobile device, track the current version of your device and a host of other features.
It also has features such as waterproof and IP67 resistance. That's why the Thunder Zoom 2.0 is also suitable for harsh conditions such as rain and snow. Power is supplied by one replaceable Li-ion battery and it is possible to use an external source (power bank) for recharging. Saves battery with sleep mode.
We provide a 1-year warranty on the equipment and a guarantee to lend a spare device in the event of a need for service.
Specifications:
| Sensor | 640 × 512 px |
| NETD | ≤ 20 mK |
| Display resolution | 1024 x 768 px |
| Wi-Fi | Yes |
| Lens | 35 / 60mm |
| Detection range | 1800 / 3000 m |
| Optical magnification | 1.8x / 3.1x |
| Field of vision | 12.5° x 10.0° / 7.3° x 5.9° |
| Optical zoom | 1.7x |
| Digital zoom | 8x |
| Dioptric correction | ±5D |
| Capture snapshot option | Yes |
| Video recording option | Yes |
| Protection level | IP67 |
| Memory | built-in, 16GB |
| Operating temperature | -30°C to 55°C |
| Battery | 1x rechargeable Li-ion |
| Battery operating time | 6.5 hours |
| Weight | 843g |
| Dimensions | 254 x 69 x 81 mm |
Package contents:
- Thermal imaging sight HIKMICRO Thunder Zoom TQ60Z 2.0
- 1x device bag
- 2x rechargeable Li-ion battery
- 1x USB-C cable
- 1x battery charger
- Instructions in Czech and Slovak
Additional parameters
| Category: | Thermal imaging |
|---|---|
| Warranty: | 1 year |
| Wi-Fi: | Yes |
| Sensor: | 640 x 512 px |
| Display resolution: | 1024 × 768 px |
| NETD: | 20 mK |
| Optical magnification: | 1.8x, 3.1x |
| Lens: | 35 mm, 60mm |
| Detection (m): | 1800, 3000 |
| Battery operating time (hours): | 6,5 |
| Weight (g): | 843 |
| Model: | TQ60Z 2.0 |
| Model range: | Thunder Zoom 2.0 |
| Brand: | Hikmicro |
| Manufacturer's marking: | HM-TR56-3560S1G/W-TQ60Z 2.0 |
